Repairing a Fence Post





This technique is good if you want to repair a fence and just one or two of your fence posts are rotten and need replacing. You can fix just these posts and get more life out of your fence. When fixing fences, reusing your old concrete plugs is much easier than pulling out the old concrete plugs and trying to pour a new ones (which are in too big of a hole now because of what it takes to dig out the old ones). The good news is that the fence posts end up in the exact right place to reattach your existing sections of fence.





dig out post plug





To reuse a concrete plug, the plug must be strong and intact, as well as secure in the ground. First measure the hole to determine if a modern redwood 4x4 will fit inside (3.5x3.5, or you can have a post milled to the exact size if it is an odd shape, or old style rough cut lumber as in the example below).

First remove the rotten fence post and dig out the rotten wood lining the square hole in the concrete plug. A crowbar and your gloved fingers works the best for this.

Dig down as far as you can till you hit concrete or very packed dirt:





dig out post plug





Clean off the top of the concrete plug with a stiff brush so the morter will stick well. Then mix a little morter and put it down in the whole, enough to make a concrete seal against moisture when the fence post is lowered in:





cement in post hole





cement in post hole





Lower the entire 8 foot 4X4 into the hole (you will cut it to size after it is set). Sometimes the post is very tight in the hole. In this case, stand on a step ladder and pound with a sledge hammer untill it is seated. These holes and posts in most cases will be very similar in size. You could always belt sand a little if the post is too tight. It doesn't matter if the post is slightly smaller than the hole because we are going to shim it.

Use redwood shim hammered into the edges of the hole and the post along with a level to insure that it ends up plumb (can of course only be as plum as it was originally, but this is good enough for most repair situations):





shim in post





shim in post





When the post is plum and tightly shimmed, break off the shim right at the base of the post:





pic





pic





Now morter over the top of the plug and around the post and make sure there is a tight seal around the wood. Also, it is best to have the morter higher up against the post then around the rest of the plug so that rain runs off and doesn't sit next to the wood.

If the top of the concrete plug is very smooth, consider using a coat of concrete adhesive over the plug before you remorter over the top:





pic





pic
